HAProxy in front of Ceph Manager dashboard

HAProxy in front of Ceph Manager dashboard 150 150 Wido den Hollander

The Ceph Mgr dashboard plugin allows for an easy dashboard which can show you how your Ceph cluster is performing.

In certain situations you can’t contact the Mgr daemons directly and you have to place a Proxy server between your computer and the Mgr daemons.

This can be done easily with HAProxy and the following configuration which assumes that:

  • SSL has been disabled in the Dashboard plugin
  • Dashboard plugin listens in port 8080
  • Mgr is running on the hosts mon01, mon02 and mon03
global
  log         127.0.0.1 local1
  log         127.0.0.1 local2 notice

  chroot      /var/lib/haproxy
  pidfile     /var/run/haproxy.pid
  maxconn     4000
  user        haproxy
  group       haproxy
  daemon

  stats socket /var/lib/haproxy/stats

defaults
  log                     global
  mode                    http
  retries                 3
  timeout http-request    10s
  timeout queue           1m
  timeout connect         10s
  timeout client          1m
  timeout server          1m
  timeout http-keep-alive 10s
  timeout check           10s
  maxconn                 3000
  option                  httplog
  no option               httpclose
  no option               http-server-close
  no option               forceclose

  stats enable
  stats hide-version
  stats refresh 30s
  stats show-node
  stats uri /haproxy?stats
  stats auth admin:haproxy

frontend https
  bind *:80
  default_backend ceph-dashboard

backend ceph-dashboard
  balance roundrobin
  option httpchk GET /
  http-check expect status 200
  server mon01 mon01:8080 check
  server mon02 mon02:8080 check
  server mon03 mon03:8080 check

You can now point your browser to the URL/IP of your HAProxy and use your Ceph dashboard.

In case a Mgr machine fails the health checks of HAProxy will make sure it fails over to on of the other Mgr daemons.

VXLAN with VyOS and Ubuntu 18.04

VXLAN with VyOS and Ubuntu 18.04 150 150 Wido den Hollander

VXLAN

Virtual Extensible LAN uses encapsulation technique to encapsulate OSI layer 2 Ethernet frames within layer 4 UDP datagrams. More on this can be found on the link provided.

For a Ceph and CloudStack environment I needed to set up a Proof-of-Concept using VXLAN and some refurbished hardware. The main purpose of this PoC is to verify that VXLAN works with CloudStack, Ceph and Ubuntu 18.04

VyOS

VyOS is an open source network operating system based on Debian Linux. It supports VXLAN, so using this we were able to test VXLAN in this setup.

In production a other VXLAN capable router would be used, but for a PoC VyOS works just fine running on a regular server.

Configuration

The VyOS router is connected to ‘the internet’ with one NIC and the other NIC is connected to a switch.

Using static routes a IPv4 subnet (/24) and a IPv6 subnet (/48) are routed towards the VyOS router. These are then splitted and send to multiple VLANs.

As it took me a while to configure VXLAN under VyOS

I’m only posting that configuration.

interfaces {
    ethernet eth0 {
        address 31.25.96.130/30
        address 2a00:f10:100:1d::2/64
        duplex auto
        hw-id 00:25:90:80:ed:fe
        smp-affinity auto
        speed auto
    }
    ethernet eth5 {
        duplex auto
        hw-id a0:36:9f:0d:ab:be
        mtu 9000
        smp-affinity auto
        speed auto
        vif 300 {
            address 192.168.0.1/24
            description VXLAN
            mtu 9000
        }
    vxlan vxlan1000 {
        address 10.0.0.1/23
        address 2a00:f10:114:1000::1/64
        group 239.0.3.232
        ip {
            enable-arp-accept
            enable-arp-announce
        }
        ipv6 {
            dup-addr-detect-transmits 1
            router-advert {
                cur-hop-limit 64
                link-mtu 1500
                managed-flag false
                max-interval 600
                name-server 2a00:f10:ff04:153::53
                name-server 2a00:f10:ff04:253::53
                other-config-flag false
                prefix 2a00:f10:114:1000::/64 {
                    autonomous-flag true
                    on-link-flag true
                    valid-lifetime 2592000
                }
                reachable-time 0
                retrans-timer 0
                send-advert true
            }
        }
        link eth5.300
        mtu 1500
        vni 1000
    }
    vxlan vxlan2000 {
        address 109.72.91.1/26
        address 2a00:f10:114:2000::1/64
        group 239.0.7.208
        ipv6 {
            dup-addr-detect-transmits 1
            router-advert {
                cur-hop-limit 64
                link-mtu 1500
                managed-flag false
                max-interval 600
                name-server 2a00:f10:ff04:153::53
                name-server 2a00:f10:ff04:253::53
                other-config-flag false
                prefix 2a00:f10:114:2000::/64 {
                    autonomous-flag true
                    on-link-flag true
                    valid-lifetime 2592000
                }
                reachable-time 0
                retrans-timer 0
                send-advert true
            }
        }
        link eth5.300
        mtu 1500
        vni 2000
    }
}

VLAN 300 on eth5 is used to route VNI 1000 and 2000 in their own multicast groups.

The MTU of eth5 is set to 9000 so that the encapsulated traffic of VXLAN can still be 1500 bytes.

Ubuntu 18.04

To test if VXLAN was actually working on the Ubuntu 18.04 host I made a very simple script:

ip link add vxlan1000 type vxlan id 1000 dstport 4789 group 239.0.3.232 dev vlan300 ttl 5
ip link set up dev vxlan1000
ip addr add 10.0.0.11/23 dev vxlan1000
ip addr add 2a00:f10:114:1000::101/64 dev vxlan1000

That works! I can ping 10.0.0.11 and 2a00:f10:114:1000::1 from my Ubuntu 18.04 machine!

Ceph Monitors are laggy or clock might be skewed

Ceph Monitors are laggy or clock might be skewed 150 150 Wido den Hollander

This weekend I got to investigate a Ceph cluster which had issues where the Monitors were constantly performing new elections.

After some investigation on of the three monitors was eating 100% CPU on a single core and kept printing this in the logs:

mon.charlie@2(peon).paxos(paxos updating c 106399655..106400232) lease_expire from mon.0 [2a00:XXX:121:XXX::6789:1]:6789/0 is 2.380296 seconds in the past; mons are probably laggy (or possibly clocks are too skewed)

Digging further I found that the LevelDB store in /var/lib/ceph/mon/X/store.db was 2.5GB in size.

Compact on Start

You can tell the monitor to compact the LevelDB database on start. Add the following to your ceph.conf:

[mon]
mon compact on start = true

Now restart the monitor and it will compact the LevelDB database.

The CPU usage now dropped and the monitors were happy again.

Calculating RADOS objects for RBD images

Calculating RADOS objects for RBD images 150 150 Wido den Hollander

Ceph’s RBD (RADOS Block Device) is just a thin wrapper on top of RADOS, the object store of Ceph.

It stripes (by default) over 4MB objects in RADOS. It’s very simple to calculate which RADOS object corresponds with which sector on your RBD image/block device.

First you have to find out the block device’s object prefix name and the stripe size:

ceph@daisy:~$ sudo rbd info test
rbd image 'test':
	size 128 MB in 32 objects
	order 22 (4096 KB objects)
	block_name_prefix: rb.0.1066.2ae8944a
	format: 1
ceph@daisy:~$

In this case the stripe size is 4MB (order 2^22) and the object name prefix is rb.0.1066.2ae8944a

With one line of Perl we can calculate the object name in RADOS:

perl -e 'printf "BLOCK_NAME_PREFIX.%012x\n", ((SECTOR_OFFSET * 512) / (4 * 1024 * 1024))'

Let’s say that we want the object for sector 1 of our block device:

perl -e 'printf "rb.0.1066.2ae8944a.%012x\n", ((0 * 512) / (4 * 1024 * 1024))'

This tells us that we need to fetch object rb.0.1066.2ae8944a.000000000000 from RADOS. This can be done using the ‘rados’ command:

sudo rados -p rbd get rb.0.1066.2ae8944a.000000000000 rb.0.1066.2ae8944a.000000000000

Voila, you just fetched 4MB of your drive. Might be useful if you want to do some data recovery or such.
